JA Mono Solar Panels Pro JAM72S30GR 540W 545W 550W 555W 560W 565W 144 Cell High Quality Half cell Solar Panel

Short Description:

Assembled with 11BB PERC cells and gapless ribbon connection technology, the modulescan offer higher output power with improved module efficiency, the reduction of cells gapsbrings outstanding module appearance. The half-cell configurature makes less shading effect, lower risk of hot spot, as well as more reliable and stable power generation.


  • Brand Name: JA Solar
  • Model Number: Pro JAM72S30GR
  • Place of Origin: Jiangsu, China
  • Cell size: 182mmx182mm
  • Type: PERC, Half Cell
  • Panel Dimensions: 2278mmx1134mmx30mm
  • Panel Efficiency:: 21.90%
  • Certificate: TUV/CGC
  • Warranty: 25 years
  • Weight: 27.3kg
  • Power Tolerance: 0~+5W
  • Product name: Solar Panel Components
  • Encapsulant material: EVA/POE
  • Max Power Current: 13.32A
  • Frame: Anodized Aluminum Alloy
  • J-Box: IP68, 3 diodes
