JA Pro JAM78D30GB 585W-610W Mono-facial PERC Mono Half Cell Solar Panel

JA Pro JAM78D30GB 585W-610W Mono-facial PERC Mono Half Cell Solar Panel Featured Image
  • JA Pro JAM78D30GB 585W-610W Mono-facial PERC Mono Half Cell Solar Panel
  • JA Pro JAM78D30GB 585W-610W Mono-facial PERC Mono Half Cell Solar Panel
  • JA Pro JAM78D30GB 585W-610W Mono-facial PERC Mono Half Cell Solar Panel

Short Description:

Assembled with 11BB bifacial PERCIUM cells and gapless ribbon connection technology, these double glass modules have the capability of converting theincident light from the rear side together with the front side into electricity, providing higher output power,lower temperature coefficient, less shading loss, as well asenhanced tolerance for mechanical loading.
  • Brand Name: JA Solar
  • Model Number: Pro JAM78D30GB
  • Place of Origin: Jiangsu, China
  • Cell size: 182mmx182mm
  • Type: Bifacial, Double-glass, Half Cell, PERC
  • Panel Dimensions: 2465±2*1134±2*35±1mm
  • Panel Efficiency: 21.80%
  • Certificate: TUV/CGC
  • Warranty: 25 years
  • Weight: 34.6kg
  • Power Tolerance: 0~+5W
  • Product name: Solar Panel Components
  • Encapsulant material: EVA/POE
  • Max Power Current: 13.33A
  • Frame: Anodized Aluminum Alloy
  • J-Box: lP68, 3 diodes
  • Maximum Rated Fuse Current: 30A
  • Maximum System Voltage: 1500V DC
